General
Product Type Amplifier
Recommended Use Car
Width 7.6 in
Depth 10.2 in
Height 2.2 in
Weight 7.3 lbs
Audio System
Response Bandwidth 20 - 250 Hz
Signal-To-Noise Ratio 100 dB
Continuous Power / Channel Qty 250 Watts x 1
Amplifier Output 1-channel
Crossover Active crossover
Crossover Slope 12 dB/octave
Low Pass Frequencies 35 - 250 Hz
Bass Boost Frequency 45 Hz
Bass Boost Gain 0 to +18dB
Output Power / Total 500 Watt
Amplifier Class Class BD
Distortion Factor 0.8%
Amplifier Output Details 200 Watt - 4 Ohm - 14.4V DC - 1 channel(s)
400 Watt - 2 Ohm - 14.4V DC - 1 channel(s)
500 Watt - 1 Ohm - 14.4V DC - 1 channel(s)
Additional Features Thermal protection, subsonic filter, short circuit protection, gain control
Connections
Connector Type 1 x audio line-in ( RCA phono x 2 )
1 x audio line-out ( RCA phono x 2 )
1 x Remote Bass control ( RJ-45 )
